These 100 x 30mm square corner MAP material intumescent hinge pads are suitable for 102 x 76mm (4") fire rated hinges and are available in 1.0mm or 2.0mm thickness.

Choose from packs of 6, 24 or 100 pads, with self adhesive backing (for size or fitting information see the ‘Buying Guide’ tab).

Material & Fire Rating

• MAP (mono ammonium phosphate) based intumescent material
• BS476 part 22: 1987 - 30 and 60 minute rating
• BSEN 1634-1: 2014 - 30, 60, 90 & 120 minute rating

Features & Benefits

• FD30/60 fire rated intumescent material (see 'Specification and Downloads' tab for more information)
• This product is available in 1.0mm and 2.0mm
• FREE delivery available (see the 'Delivery Options' tab for more information)
• NEW Payment Options - Pay Later with Klarna (choose to pay in 30 days or spread the payments) see checkout for details

Current Dispatch Time

• FREE Delivery: Dispatch Same Day (order before 2pm) - approx. 48-72 hours after order received
• FAST Delivery: Dispatch Same Day (order before 2pm) - approx 24-48 hours after order received

If you require these hinge pads urgently or on a specific date please contact us and we will do our best to help.

"Intumescent pads are a requirement of up to 98% of ALL fire door hardware products.Fire Essentials offer a more COST EFFECTIVE and SAFER way to specify, buy and fit these products."

Why choose a Fire Essentials Door Product™ ?

Fire Essentials Ltd was established in 2018 by individuals from the UK fire door manufacturing sector, in order to bring a higher level of product knowledge and support to anyone installing or repairing FD30/60 timber fire doors.

If you need ANY further information about our products, service or delivery options please contact us via telephone 01305 457703, email info@fireessentials.co.uk or through our online contact form.

If you have any questions about this product or it's suitability for your specific fire door requirements, we would always recommend that you consult your fire officer or Responsible Person(s) etc BEFORE purchase or contact a member of our team and we would be happy to help. These products are fitted at your own risk and any questions or issues should be directed to the manufacturer (their details are available on request).

DOWNLOADS & FIRE DOCUMENTS

The type of material and thickness your hinge needs depends on the FIRE CERTIFICATE or TEST EVIDENCE of your hinge.

But, as a general rule, you would need 0.8mm or 1.0mm for a 30 minute fire door and 2.0mm for a 60 minute fire door.

Each hinge is also tested with either graphite or MAP (Mono Ammonium Phosphate, white in colour and commonly called by it's brand name 'Interdens') or BOTH.

Is this the right SIZE pad for my hinge?

You will need to measure the hinge (measure the long ledge of one leaf and then the short length between the edge of one leaf and the knuckle of the hinge as per the diagram on the right).

Which type of MATERIAL of intumescent do I need?

This will depend on the fire certificate or test evidence of the hinge and latch or, it will be dictated by the door certificate, just ask your fire officer or Responsible Person and they can tell you which documents to follow.

If you can't find the fire document you need please contact us as we have a database that is free to access.

Which THICKNESS of intumescent pad do I need to use?

The thickness of the material (either 0.8mm, 1.0mm or 2.0mm) will depend on the fire certificate of your ironmongery or the fire door, whichever is recommended by your fire officer or Responsible Person.

For a copy of the fire certificate just email us at info@FireEssentials.co.uk with your product details and we will send you a link to the fire document.

I still need a bit of advice, how do I find out more?

Just contact us via email (info@FireEssentials.co.uk), call 01305 457703 or visit the contact page on the website and a member of our technical team would be happy to help.

As with EVERYTHING on a fire door, if in doubt, ask the person responsible for your fire doors for advice BEFORE purchasing or fitting any products.
