24 No. 100 x 30mm MAP Radius Intumescent Hinge pads (2.0mm)

24 Pack of 2.0mm radius MAP intumescent hinge pads

roll over the image to zoom in

24 No. 100 x 30mm MAP Radius Intumescent Hinge pads (2.0mm)

£30.98 (inc. VAT)
£25.82 (ex. VAT)
reward points

Product details

4-plus-banner.pngThis pack contains 24 No. 100 x 30mm MAP (Mono Ammonium Phosphate) RADIUS style intumescent hinge pads.

Want to COMPARE our prices for the intumescent pads?

Two pdf versions of the our Intumescent Price List are available to download:

Product Features

  • Fire rated for use with FD30/60 Hinges (see buyers guide below)
  • 2.0mm material (also available in 1.0mm)

Each Pack Contains

  • 24 No. 100 x 30 x 2.0mm MAP Radius self adhesive intumescent hinge pads

Need FIRE documents? Find downloads at the end of the description below.

Not sure which pad you need? (Skip to bottom of page for our 'Quick Buyers Guide')

Technical Information


Product TypeIntumescent Hinge Pad
MaterialMAP, Mono Ammonium Phosphate Based Intumescent (also available in black/graphite)
BrandInterdens (click here to download the material data sheet)
Fire RatingFire Rated to 30mins & 60mins (see 'buyers guide' below for details)
Product Length100mm (other lengths are available, get a quick quote)
Product Width30mm (other widths available, get a quick quote)
Product Thickness2.0mm (also available in 1.0mm)
Hinge StyleRadius (curved) corner (also available with square corner)
Finish OptionsSelf Adhesive (Plain pads available, get a quick quote)
Pack Size(s)24 Pack (to view packs of 6 or 100 Pads)
Internal/External UsageInternal
Manufacturer GuaranteePlease contact us for details


The type of material and thickness your hinge needs depends on the FIRE CERTIFICATE or TEST EVIDENCE of your hinge.

But, as a general rule, you would need 1.0mm for a 30 minute fire door and 2.0mm for a 60 minute fire door.

Each hinge is also tested with either graphite or MAP (Mono Ammonium Phosphate, white in colour and commonly called by it's brand name 'Interdens') or BOTH.

Buyers TIP: Graphite material (if an option for you) is CHEAPER, nicer to handle and made in the UK.

If you are not sure of the specific requirements of your hinge please ask your fire officer or contact us for advice.


Document TypeMaterial Data Sheet (white/MAP)

For more fire certificates, data sheets or product brochures please email us on info@FireEssentials.co.uk or call us on 01305 457703.

If you have any questions about this product or it's suitability to your specific fire door requirements, we would always recommend that you contact your fire officer or Responsible Person(s) etc.. BEFORE purchasing or, contact a member of our team and we would be happy to help.
